1. SOM LAB :

Strength of material course is offered to degree and diploma students and is an important part of the course curriculum. The SOM laboratory contains machines for testing of material like mild steel, copper, aluminium, cubes, and bricks etc. The students are able to synergies the theory with the practical.

List of the Important Equipments in the laboratory:

• Universal Testing Machine
• Brinell Hardness Testing Machine
• Vickers Hardness Testing Machine
• Torsion Testing Machine
• Impact Testing Machine

2. FM LAB :

Matter exists in either the solid state or the fluid state. The fluid state is further divided into the liquid and the gaseous states. A fluid is a substance which is capable of flowing. A liquid is a fluid, which possesses definite volume which varies slightly with temperature and pressure. Under ordinary conditions, liquids are considered as incompressible fluid. Fluid mechanics is that the branch of Engg. science which deals with the behavior of the fluids at rest as well as in motion. In general the scope of fluid mechanics is very wide which includes the study of all gases and liquids. Fluid mechanics deals with the analysis and methods to solve many engineering problems involving liquid flow, such as flow through pipes or channels, storage dams, pumps and water turbines, hydraulically operated machines such as lift, crane, press etc. Hence it is essential for the engineering students of Civil, Mechanical, and allied branches of engineering to understand the theoretical and practical aspects of fluid mechanics

List of the Important Equipments in the laboratory:

• Pelton Wheel Turbine
• Francis Turbine
• Kaplan Turbine
• Hydraulic Ram
• Centrifugal Pump Test Rig
• Venturimeter
• Orifice Meter

3. Basic Mechanical Engineering Lab.

Mechanical Engineering is often considered as the most basic type of engineering work. It is probably the first branch of engineering which has vast applications in all fields. Mechanical engineers were responsible for Industrial Revolution and innovations like the steam engine, internal combustion engines, turbines, compressors, pneumatic machines, machine tools, refrigeration and air conditioning systems, etc done by mechanical engineers. Therefore every student should know the basic of mechanical engineering. This lab has the purpose to bring in understanding of the basic concepts of mechanical engineering and develop as core professional.

List of the Important Equipments in the laboratory:

• Two Stroke Petrol Engine Model
• Two Stroke Diesel Engine Model
• Four Stroke Petrol Engine Model
• Four Stroke Diesel Engine Model
• Cochran Boiler Model
• Babcock and Wilcox Boiler Model
• Single Start Worm & Worm Wheel Model
• Double Start Worm & Worm Wheel Model
• Triple Start Worm & Worm Wheel Model
• Mountings and Accessories in Boiler Models

4. Engineering Mechanics Lab.

This laboratory gives the basic understanding of structural member under the action of loads. The students will experience the changes in behaviour of structure due to application of loads. Basics of determinate structures will be introduced through experiment.

The main purpose of any structure is to support the loads coming on it by properly transferring them to the foundation. The students will be able to compute internal, external forces and displacements produced by the application of loads to make the structure safe. Detailed analysis is to be performed to determine the bending moments, shear force, axial forces etc at the required section.

List of the Important Equipments in the laboratory:

• Simply supported beam
• Belt friction
• Sliding friction
• Fly wheel
• Worm & Worm wheel
• Screw jack
• Winch crab – single purchase
• Pulley block

5. Heat Transfer lab

The objective of this lab is to understand the concepts of conduction, convection and radiation practically in various thermal systems to under graduate and Post graduate students through a series of experiments. Students have a fairly good understanding of the theory underlying the experiments and the entire lab course is designed such that classroom lectures precede the lab work. The Heat Transfer Laboratory is equipped with test facilities for doing research with in internal combustion engines for energy conversion.

List of the Important Equipments in the laboratory:

• Thermal conductivity of insulating powder
• Heat transfer through natural convection
• Refrigeration test rig
• Heat transfer in forced convection
• Heat transfer from a pin-fin (natural convection)
• Heat transfer from pin-fin (forced convection)
• Emissivity apparatus
• Shell and tube heat exchanger
• Thermal conductivity of liquid
• Multiple effect evaporator
• Shell and tube heat exchanger
• Dropwise and filmwise condensation apparatus

6. Automobile Engineering Lab.

The objective of this lab is to understand the concept of the working of different components and systems which are involved in an automobile. It provides a sound knowledge to students about the operation and maintenance of the automobile. This laboratory has a scope to equip the student with maximum knowledge about the modern vehicle design and latest technology and development in automobile engineering.

List of the Important Equipments in the laboratory:

• Cut section models of different Automobile Assemblies
• Electrical Systems
• Actual Cut Section Model Of 4-Stroke Diesel Engine
• Gear Box
• Steering Mechanisms
• Cooling systems
• Power steering system

7. Material Science lab :

The Materials Science Labs allows for the evaluation, development and redesign of materials for specific properties and improved performance characteristics. Correlative characterisation and tomography of material properties for computer-based simulations and analysis can be undertaken.

List of the Important Equipments in the laboratory:

• Izod Impact Testing Machine.
• Motorized Rockwell Hardness Tester.
• Tensile Strength Testing Machine.
• Torsion Testing Machine.
• Fatigue Testing Machine.
• Brinnell Hardness Tester.
• Universal Testing Machine.
• Polishing machine.
• Metallurgical Microscope.

8. CAD/CAM Lab.

Before we design and manufacture any component, the object must be presented in the form of drawings along with different views and dimensions. Further, the bill of materials etc. must also be supplied. With the advent of computers and relevant software packages, the drafting drifted from manual to computer aided drafting. The networking between the shop floor sections and design sections makes it easier to share the data and information. The modifications (in the drawings, materials or process of operation) if required, can be discussed on line and can be implemented without any time lag.

The use of interactive graphics programs to develop 2D and 3D models, assemblies, part lists, and dimensional drawings of various components, structures or objects with the help of a computer is called Computer-Aided Design(CAD). The data generated by a CAD system can be directly utilized by a CAM (Computer Aided Manufacturing) system. Thus, CAD and CAM are interrelated to each other.

List of the Important Equipments in the laboratory:

• AUTO CAD software
• Computer system with minimum 2GB RAM.

9. Internal combustion Engine Lab :

An Internal Combustion Engine converts chemical energy into mechanical work to run different systems of vehicle. Aim behind this laboratory work is to teach student about basic laws of thermodynamics, heat transfer between various systems and conversion of heat to one form to another form. Students can enhance their knowledge by applying theoretical principle to practical skills. A range of different engines and fuels make students eager to brush their knowledge. After learning, students can understand difference between working of SI and CI engines, evaluate parameters of emissions and understand performance parameters of different engines.

List of the Important Equipments in the laboratory:

• 4 Cylinder 4 Stroke, Water cooled Petrol Engine
• Single Cylinder 4 Stroke Air cooled Petrol Engine
• Single Cylinder 2 Stroke Air Cooled Petrol Engine
• Single Cylinder 4 Stroke Air Cooled Diesel Engine
• Gas Analyzer for Measurement
• Motor driven cut section Model of Single Cylinder 2 Stroke Petrol engine
• Cut section Model of actual Single Cylinder 4 Stroke Diesel Engine

10. Work Shop :

Mechanical Engineering Workshop is a place where students acquire knowledge on the operation of various processes involved in manufacturing and production. The Workshop Practice course makes students competent in handling practical work in engineering environment. Mechanical Engineering Workshop is also involved in different maintenance/repair works for Institute.

List of the Important Equipments in the laboratory:

• Gas Welding Machine
• Metal Arc Welding Machine
• Lathe Machine
• Milling Machine
• Radial Drilling Machine
• Hydraulic Power Hacksaw
• Drilling Machine
• Grinding Machine
• Shaper Machine

11. Theory of Machine Lab :

Objectives of this Theory of Machines lab are to impart practical knowledge on design and analysis of mechanisms for the specified type of motion in a machine. With the study of rigid bodies motions and forces for the transmission systems, machine kinematics and dynamics can be well understood.

Demonstration exercises are provided with wide varieties of transmission element models to understand machine kinematics. Various experiments with governors, gyroscopes, balancing machines and universal vibration facilities are available to understand machine dynamics.

List of the Important Equipments in the laboratory:

• Cam analysis apparatus
• Epicyclic Gear Train and Torque apparatus
• Universal governor apparatus
• Motorised Gyroscope apparatus
• Static & Dynamic balancing Apparatus
• Inversions of Four bar Chain (Different Types)
• Inversions of Single slider crank chain (Different Types)
• Inversions of Double slider crank chain (Different Types)
• Cam and Follower Arrangement (Different Types)
• Gear And Gear train Models (Different Types)

12. Refrigeration and Air-Conditioning lab :

This laboratory deals to make students to understand the methods of producing the refrigeration and air conditioning. It gives students an understanding about the working of different types of refrigeration devices and their performance calculation. In this one would know how the air is conditioned to provide the comfort conditions for human beings.

List of the Important Equipments in the laboratory:

• Refrigeration Test RIG
• Window AC Test RIG
• Ice Plant Test Rig
• Heat Pump Test Rig
• Water Cooler Test Rig
• Air Conditioning Test Rig
• Vapour compression Refrigeration Test Rig
